TEFCOLD · SKU blca3x1

Blast chiller/freezer BLCA3X1

Manufacturer article: 54811Previous manufacturer article: 16386Previous model: BLC3

Compact blast chiller/freezer for three GN 1/1 pans, chilling 12 kg from +70 to +3 °C in 90 minutes and freezing 8 kg in 240 minutes.

Temperature
−30…+70 °C
Dimensions
804x826x995

Price on request

Request a quote for the price and delivery time.Available to order · delivery 2–5 weeks

Request a quote
Call sales +372 5559 3678
About this product

Description

The Tefcold BLCA3X1 brings hot food straight from the stove or oven down to a safe storage temperature, either chilled or frozen. The cabinet takes three GN 1/1 pans, with guides that also accept Euronorm trays (pans not included). The stainless-steel body stands on four adjustable feet.

A touchscreen controller offers preset programmes, including special cycles for fish, ice-cream hardening, drying and defrosting, and lets staff create and save their own. A core probe is supplied. Recipes can be uploaded and HACCP data downloaded through a USB port.

The main programmes hold the end temperature until the door is opened and the programme is switched off. The self-closing door is reversible, and defrost is automatic by hot gas. Blast chilling from +70 to +3 °C in 90 minutes (12 kg); blast freezing from +70 to −18 °C in 240 minutes (8 kg).

Refrigerant R290, rated power 700 W, noise 60 dB(A). Volume 60 litres net (139 litres gross); external 804 × 826 × 995 mm, internal 660 × 640 × 330 mm; net weight 104 kg.

If the unit ever breaks down at your business, our own service team can carry out the blast chiller repair.

Technical data

Specifications

Type
Blast chiller/freezer
Manufacturer
TEFCOLD
Model name
BLCA3X1
Gross volume; litres
139
Net volume; litres
60
External dimensions (W×D×H); mm
804x826x995
Internal dimensions (W×D×H); mm
660x640x330
Operating capacity
Blast chilling from +70° to +3°C in 90 minutes; blast freezing from +70 to -18 °C in 240 minutes.
Temperature adjustment range
−30…+70 °C
Electrical connection
220-240 V / 50Hz
Electrical power; W
700
Gross and net weight; kg
130 / 104
Noise level; dBA
60
Exterior finish
AISI stainless steel SS304
Interior finish
AISI stainless steel SS304
Door / drawer
Right-hinged self-closing solid door; reversible
Handle
Integrated
Lock
No
Shelves
GN tray capacity: 3 x GN1/1
Feet / castors
Adjustable feet 4 pcs.
Refrigerant
R290
Cooling
Blast chilling
Defrosting
Automatic hot-gas defrost
Defrost water evaporation
Automatic
Temperature controller
Electronic, programmable
Thermometer
Digital
Other information
Blast chilling cycle: +70 °C → +3 °C in 90 minutes. Blast freezing cycle: +70 °C → −18 °C in 240 minutes.
Warranty
12 months
